Origin Storage Inception TLC830 Pro Series 512GB 2.5in SATA III 3D TLC SSD 6Gb/s 7mm

Inception TLC830 Pro Series 512GB 2.5in SATA III 3D TLC SSD 6Gb/s 7mm

Key Features

• Read Intensive, Mobile/Desktop Based, Professional Solutions
• Does not invalidate OEM warranty
• 100% compatible replacement/upgrade for storage solutions
• Pre- & Post-Sale UK Based Tech Support

Description

The Inception TLC830 Pro range of SSD Solutions are manufactured by Origin using the highest quality Tier 1 NAND and the latest generation of controllers which enables us to provide both high performance and strong reliability. All of our Inception SSDs come with 3 years advanced replacement warranty alongside free, in -house pre and post sales technical support. We can supply the TLC830 Pro in form factors of 2.5", 3.5" & M.2 with either SATA or NVME interfaces, whilst being available in a range of capacities designed to increase the performance & extend the lifecycle of any laptop or desktop.

Specifications

Hard drive
SSD capacity	512 GB
Memory type	3D TLC
Seek time	0 ms
Access time	0.1 ms
Performance
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Interface	Serial ATA
Component for	PC/Laptop
NVMe	No
Low-density parity-check (LDPC)	Yes
TBW rating	200
Hot-swap	No
SSD capacity	512 GB
S.M.A.R.T. support	Yes
Read speed	540 MB/s
Write speed	520 MB/s
ECC	Yes
Memory type	3D TLC
Random write (4KB)	58880 IOPS
Random read (4KB)	53760 IOPS
Seek time	0 ms
Mean time between failures (MTBF)	1000000 h
Hardware encryption	No
Data transfer rate	6 Gbit/s
Access time	0.1 ms
Compatible products	Universal
Data transmission
Read speed	540 MB/s
Write speed	520 MB/s
Random write (4KB)	58880 IOPS
Random read (4KB)	53760 IOPS
Data transfer rate	6 Gbit/s
Endurance
Mean time between failures (MTBF)	1000000 h
Features
Interface	Serial ATA
Component for	PC/Laptop
NVMe	No
Low-density parity-check (LDPC)	Yes
TBW rating	200
Hot-swap	No
SSD capacity	512 GB
Windows operating systems supported	Yes
S.M.A.R.T. support	Yes
Read speed	540 MB/s
Write speed	520 MB/s
Linux operating systems supported	Yes
ECC	Yes
Memory type	3D TLC
Random write (4KB)	58880 IOPS
Random read (4KB)	53760 IOPS
Seek time	0 ms
Mean time between failures (MTBF)	1000000 h
Hardware encryption	No
Data transfer rate	6 Gbit/s
Access time	0.1 ms
SSD form factor	2.5"
Compatible products	Universal
Harmonized System (HS) code	84717070
Power
Power consumption (write)	4.26 W
Power consumption (read)	2.48 W
Power consumption (idle)	0.47 W
Operating voltage	5 V
Design
Component for	PC/Laptop
SSD form factor	2.5"
Packaging data
Storage drive adapter included	No
Package type	Blister
Screws included	No
System requirements
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 98%
Storage relative humidity (H-H)	5 - 98%
Operating shock	1500 G
Operating vibration	16 G
Maximum operating altitude	120000 m
Technical details
Interface	Serial ATA
Hot-swap	No
S.M.A.R.T. support	Yes
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 98%
ECC	Yes
Storage relative humidity (H-H)	5 - 98%
Operating shock	1500 G
Operating vibration	16 G
Maximum operating altitude	120000 m
Hardware encryption	No
SSD form factor	2.5"
Compliance certificates	RoHS
Software
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Weight & dimensions
Package type	Blister
Other features
Compatible products	Universal
Compliance certificates	RoHS
Packaging content
Storage drive adapter included	No
Screws included	No
Logistics data
Harmonized System (HS) code	84717070
