Description
2.5Gb Ethernet Dual-WAN Firewall Router & VPN Concentrator
The Vigor 2962 provides a reliable, flexible, and secure network solution with extensive Firewall, Content Filtering, VPN client/server and Quality of Service controls.
An ideal VPN concentrator with 500Mbps SSL VPN performance. Connect up to 50 SSL VPN & OpenVPN users, or 200 IPsec tunnels, simultaneously. With up to 20 LAN subnets, BGP and OSPF, it’s well equipped to manage larger, more complex networks and Multi Occupancy Offices.
Key Features
- High Performance Dual WAN Router
- Manage Multiple Networks
- Capable SSL VPN Concentrator
- Flexible LAN/WAN Ports
- Packed With Features
- Great Central Management
Description
The DrayTek Vigor 2962 Dual-WAN Load Balancing Firewall VPN router surpasses Gigabit speeds, to get the best performance out of FTTP Fibre Broadband and more. Connects to 2.5Gb Ethernet and SFP Fibre, for LAN or WAN use.The Vigor 2962 provides a reliable, flexible, and secure network solution with extensive Firewall, Content Filtering, VPN client/server and Quality of Service controls.
An ideal VPN concentrator with 500Mbps SSL VPN performance. Connect up to 50 SSL VPN & OpenVPN users, or 200 IPsec tunnels, simultaneously. With up to 20 LAN subnets, BGP and OSPF, it’s well equipped to manage larger, more complex networks and Multi Occupancy Offices.
Specifications
| Ethernet LAN features | |
|---|---|
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Network | |
| Network address translation (NAT) | Yes |
| Port forwarding | Yes |
| Traffic control | Yes |
| Networking standards | IEEE 802.1Q |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Throughput | 2.2 Gbit/s |
| Forwarding rate | 900 Mpps |
| Multicast support | Yes |
| Policy-based routing | Yes |
| VLAN support | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Performance | |
| Traffic control | Yes |
| Firmware upgradeable | Yes |
| WAN connection | |
| Ethernet WAN | Yes |
| Mobile network | |
| Mobile network generation | Not supported |
| Management features | |
| Firmware upgradeable | Yes |
| Web-based management | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Ports & interfaces | |
| USB ports quantity | 2 |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| Ethernet LAN (RJ-45) ports | 4 |
| Protocols | |
| Routing protocols | RIP-1, RIP-2, RIPng |
| DMZ support | Yes |
| DHCP server | Yes |
| DHCP client | Yes |
| IPv4 & IPv6 features | Dual stack IPv4/IPv6 |
| Technical details | |
| Rack mounting | Yes |
| Firmware upgradeable | Yes |
| LED indicators | Activity, USB |
| Product colour | Black, White |
| Policy-based routing | Yes |
| Harmonized System (HS) code | 85176990 |
| Security | |
| DoS attack prevention | Yes |
| Network address translation (NAT) | Yes |
| URL filtering | Yes |
| Firewall | Yes |
| Security algorithms | HTTPS, SSH |
| VPN tunnels quantity | 200 |
| MAC address filtering | Yes |
| Design | |
| Rack mounting | Yes |
| LED indicators | Activity, USB |
| Product colour | Black, White |
| Power | |
| AC input voltage | 220 - 240 V |
| Power consumption (typical) | 15 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 273 mm |
| Depth | 170 mm |
| Height | 45 mm |
| Weight | 1.7 kg |
| Packaging data | |
| AC adapter included | Yes |
| Quick start guide | Yes |
| Cables included | LAN (RJ-45) |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Packaging content | |
| AC adapter included | Yes |
| Quick start guide | Yes |
| Cables included | LAN (RJ-45) |
