Description
DiskStation DS925+, Up to 180 TB of raw storage with expansion unit, Two built-in 2.5GbE ports and over 522/565 MB/s sequential read/write
Description
2.5GbE connectivity and diverse storage options The DS925+ features built-in 2.5GbE networking and supports both SATA flash drives and HDDs in 2.5"/3.5" internal bays, as well as M.2 NVMe drives via M.2 slots for use as either cache or storage poolsSpecifications
| Storage | |
|---|---|
| Total installed storage capacity | 64 TB |
| Storage drives installed | Yes |
| Installed storage drive type | HDD |
| Number of storage drives installed | 9 |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 9 |
| Maximum supported storage capacity | 180 TB |
| Storage drive interface | M.2, Serial ATA |
| Hot-swap drive bays | Yes |
| RAID support | Yes |
| Supported file systems | BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Supported storage drive interfaces | M.2, Serial ATA |
| Storage drive sizes supported | 2.5,3.5,M.2 |
| Number of M.2 (M & B) slots | 2 |
| Processor | |
| Processor generation | AMD Ryzen Embedded V1000 Series |
| Processor manufacturer | AMD |
| Processor threads | 8 |
| Processor frequency | 2.2 GHz |
| Processor family | Ryzen Embedded |
| Processor model | V1500B |
| Processor cores | 4 |
| Memory | |
| Internal memory type | DDR4 |
| Internal memory | 4 GB |
| Maximum RAM supported | 32 GB |
| Memory slots | 2 |
| Memory form factor | SO-DIMM |
| ECC | Yes |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 2500 Mbit/s |
| Wake-on-LAN ready | Yes |
| Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
| Ports & interfaces | |
| USB port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| Hard drive | |
| RAID support | Yes |
| Supported file systems | BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Design | |
| Fan diameter 2 | 9.2 cm |
| Cooling type | Active |
| Fan diameter | 9.2 cm |
| Drive bay locking | Yes |
| Product colour | Black |
| Number of fans | 2 fan(s) |
| LED indicators | Yes |
| Technical details | |
| Type | NAS |
| Device class | Home & Home Office |
| Backup function | Yes |
| Backup features | Cloud, iSCSI LUN |
| Product colour | Black |
| Number of users | 512 user(s) |
| Noise level | 20.5 dB |
| Multilingual support | Yes |
| LED indicators | Yes |
| Number of fans | 2 fan(s) |
| Compliance certificates | RoHS |
| Performance | |
| System log | No |
| Browser supported | Chrome,Firefox,Edge,Safari |
| Type | NAS |
| Device class | Home & Home Office |
| Backup function | Yes |
| Backup features | Cloud, iSCSI LUN |
| On/off switch | Yes |
| Web-based management | Yes |
| Number of users | 512 user(s) |
| Noise level | 20.5 dB |
| Multilingual support | Yes |
| Access Control List (ACL) | Yes |
| Snapshot | Yes |
| Cooling | |
| Cooling type | Active |
| Fan diameter | 9.2 cm |
| Number of fans | 2 fan(s) |
| Security | |
| Drive bay locking | Yes |
| Access Control List (ACL) | Yes |
| Management features | |
| On/off switch | Yes |
| Web-based management | Yes |
| Power | |
| Power consumption (HDD standby) | 12.33 W |
| Power supply location | External |
| Power supply unit (PSU) capacity | 100 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 37.91 W |
| External power adapter | Yes |
| Weight & dimensions | |
| Width | 199 mm |
| Depth | 223 mm |
| Height | 166 mm |
| Weight | 2.26 kg |
| Packaging content | |
| External power adapter | Yes |
| Cables included | AC, LAN (RJ-45) |
| Power cables quantity | 1 |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Certificates | |
| Certification | FCC CE BSMI VCCI RCM UKCA EAC CCC KC BIS |
| Packaging data | |
| Cables included | AC, LAN (RJ-45) |
| Other features | |
| Certification | FCC CE BSMI VCCI RCM UKCA EAC CCC KC BIS |
| Compliance certificates | RoHS |
